As one of the leading gritted frp molded grating manufacturers and suppliers in China, we warmly welcome you to wholesale bulk gritted frp molded grating for sale here from our factory. All products are with high quality and competitive pric...
►Available Sizes
Thickness:
13mm, 19mm, 25mm, 30mm, 32mm, 38mm & 50mm
Aperture:
38mmx38mm (in 13mm, 19mm, 25mm, 30mm, 32mm, 38mm depth)
50mmx50mm (in 50mm depth)
Load Baring:
3.0kN/m^2 – 5.0kN/m^2 – 7.5kN/m^2
Standard Panels:
2000x1000mm, 3000x1000mm, 4000x1000mm, 3660x1220mm
Standard Colours:
Green RAL 6017, Dark Grey RAL 7043, Light Grey RAL 7040, Yellow RAL 1003, Antique Brown, (Other standard RAL’s can be supplied upon request subject to increased leadtimes)
Fire Rating:
ASTM E84 Class1 <25mm
| Grid Type | No. | Thickness | Mesh Size | Panel Size | Open Area | Weight |
| (mm) | (mm) | (mm) | % | (kg/m2) | ||
|
Square Mesh |
1 | 13 | 50.8×50.8 | 3660×1220 | 76% | 5 |
| 2 | 15 | 38.1×38.1 | 3660×1220 | 69% | 6.9 | |
| 3 | 20 | 38.1×38.1 | 3660×1220 | 69% | 9.3 | |
| 4 | 20 | 40×40 | 4047×1007 | 70% | 9.2 | |
| 5 | 25 | 38.1×38.1 | 3665×1225 | 69% | 12.3 | |
| 6 | 25 | 40×40 | 4047×1007 | 70% | 12.2 | |
| 7 | 30 | 38.1×38.1 | 4008×1525 | 68% | 14.5 | |
| 8 | 30 | 40×40 | 4047×1007 | 69% | 14.3 | |
| 9 | 38 | 38.1×38.1 | 4005×1525 | 66% | 18.8 | |
| 10 | 38 | 40×40 | 4047×1007 | 67% | 18.6 | |
| 11 | 40 | 40×40 | 4047×1247 | 67% | 20 | |
| 12 | 40 | 50.7×50.7 | 3660×1225 | 69% | 16.7 | |
| 13 | 50 | 50.7×50.7 | 4115×1530 | 69% | 20.8 | |
| 14 | 50 | 50.7×50.7 | 3660×1225 | 68% | 23.5 | |
| 15 | 50 | 49.7×49.7 | 2000×1275 | 68% | 21 | |
| 16 | 50 | 38.1×38.1 | 3660×1220 | 58% | 28.7 | |
| 17 | 50 | 38.1×38.1 | 3665×1225 | 48% | 40.5 | |
| 18 | 60 | 38.1×38.1 | 3660×1220 | 58% | 36.5 | |
| 19 | 60 | 38.1×38.1 | 3670×1230 | 46% | 49.3 | |
| 20 | 63 | 38.1×38.1 | 3660×1220 | 58% | 37.4 | |
| 21 | 63 | 38.1×38.1 | 3670×1230 | 46% | 50.4 | |
| 22 | P 30 | 38.1×38.1 | 3660×1220 | 68% | 14 | |
| 23 | P 38 | 38.1×38.1 | 3660×1220 | 66% | 17.5 | |
| 24 | P 50 | 50.7×50.7 | 3660×1225 | 68% | 21.5 | |
|
Rectangle mesh |
25 | 25 | 25×100 | 3007×1009 | 67% | 13.7 |
| 26 | 25 | 25.4×101.6 | 3660×1220 | 67% | 12.5 | |
| 27 | 25 | 101.6x25.4 | 3665×1225 | 67% | 12.2 | |
| 28 | 30 | 152.4×25.4 | 3665×1226 | 68% | 16.1 | |
| 29 | 30 | 101.6×38.1 | 3660×1220 | 76% | 11.4 | |
| 30 | 38 | 152.4×25.4 | 3665×1226 | 68% | 20.4 | |
| 31 | 38 | 101.6×38.1 | 3660×1220 | 76% | 14.5 | |
| 32 | 40 | 220×60 | 2207×1507 | 85% | 9.2 | |
| 33 | 40 | 152.4×38.1 | 3660×1220 | 72% | 16.5 | |
| 34 | 50 | 152.4×38.1 | 3660×1220 | 72% | 20.8 | |
|
Mini mesh |
35 | 15 | 25.4×25.4(50.8×50.8) | 3660×1220 | 57% | 7.2 |
| 36 | 15 | 20×20(40×40) | 4047×1247 | 47% | 11.5 | |
| 37 | 20 | 12.8×12.8×12.8(38.5×38.5) | 3434×970 | 27% | 18.5 | |
| 38 | 25 | 19×19(38×38) | 4005×1220 | 44% | 14.2 | |
| 39 | 30 | 20×20(40×40) | 4047×1247 | 42% | 17.2 | |
| 40 | 30 | 12.6×12.6×12.6(38×38) | 4040×1220 | 30% | 22 | |
| 41 | 30 | 26×26(52×52) | 4011×1150 | 56% | 13.6 | |
| 42 | 38 | 19×19(38.1×38.1) | 4045×1220 | 40% | 22.3 | |
| 43 | 38 | 20×20(40×40) | 4047×1247 | 42% | 22 | |
| 44 | 38 | 26×26(52×52) | 4010×1255 | 53% | 18.5 | |
| 45 | 40 | 20×20(40×40) | 4047×1247 | 42% | 23.7 | |
| 46 | 50 | 25.35×25.35(50.7×50.7) | 3660×1220 | 47% | 25.4 |
